VEGA 物位计

VEGA雷达式物位计 VEGAPULS WL61,61,62,63,64,65,66

Instrument type Picture Measuring range Accuracy Process fitting  Process tempe rature  Process pressure VEGAPULS WL 61 Liquids, in the water and sewage management up to 15 m, +/- 2 mm Thread G1½, mounting strap, compression flanges from DN 80, 3" -40 … +80 °C -1 … +2 bar (-100 … +200 kPa) VEGAPULS 61 Liquids under easy process conditions up to 35 m, +/- 2 mm Thread G1½ 1½NPT, mounting strap, compression flanges from DN 80, 3" -40 … +80 °C -1 … +3 bar (-100 … +300 kPa) ...

VEGA雷达式物位计VEGAPULS67,68

Instrument type Picture Measuring range Accuracy Process fitting Process tempe rature Process pressure VEGAPULS 67 Bulk solids under easy pro-cess conditions up to 15 m, +/- 2 mm Mounting strap, compression flanges from DN 80, 3" -40 … +80 °C -1 … +2 bar (-100 … +200 kPa) VEGAPULS SR 68 Bulk solids also under arduous process conditions up to 30 m, +/- 2 mm Thread G1½ 1½NPT, flanges from DN 50, 2" -40 … +250 °C -1 … +100 bar (-100 … +10000 kPa) VEGAPULS 68 Bulk solids also under arduous process conditi...

导向微波式 VEGAFLEX 61,67



电容式 VEGACAL 62,67

Instrument type  Picture Version Measuring range  Process fitting  Process tempe rature  Process pressure  VEGACAL 62 Bulk solids, non-conductive liquids    partly insulated rod, up to 6 m  Thread from G½, ½ NPT, flange from DN 25, 1“  -50 … +200 °C  -1 … +64 bar (-100 … +6400 kPa)  VEGACAL 63 Conduct...

超声波式 VEGASON 61,62,63,64,65

液体介质   固体介质
